Puma VT900M

DN Solutions (formerly Doosan) Puma VT900M Single Turret Vertical Lathe

PUMA VT1100M with Automatic tool changer Watch this Video

Puma VT900M Description

DN Solutions (formerly Doosan) Puma VT900M Single Turret Vertical Lathe

Product specifications

Doosan Puma VT900M Single Turret Vertical Turret Lathe

Puma VT900M

View
Doosan Puma VT1100M Single Turret Vertical Turret Lathe

Puma VT1100M

View
Doosan Puma VT900 Single Turret Vertical Turret Lathe

Puma VT1100

View
Doosan Puma VT900 Single Turret Vertical Turret Lathe

Puma VT900

View
Puma VT900M
Puma VT1100M
Puma VT1100
Puma VT900
Travels
X Axis Rapid Traverse
20 m/min
20 m/min
20 m/min
20 m/min
Z Axis Rapid Traverse
20 m/min
20 m/min
20 m/min
20 m/min
X Axis Travel distance
470 mm
580 mm
580 mm
470 mm
Z Axis Travel distance
850 mm
1000 mm
1000 mm
850 mm
Spindle
Max. Spindle Speed
1800 r/min
850 r/min
850 r/min
1800 r/min
Max. Spindle Power
45 kW
60 kW
60 kW
45 kW
Max. Spindle Torque
4443 N·m
6385 N·m
6385 N·m
4443 N·m
Tools
No. of tool station
12
12
12
12
Product Dimensions
Length
2130mm
2830mm
2830mm
2130mm
Width
3050mm
3305mm
3305mm
3050mm
Height
3621mm
4012mm
4012mm
3621mm
Weight
12500kg
22050kg
22000kg
12500kg
Additional
Chuck size
24 inch
32 inch
32 inch
24 inch
Max. Turning Diameter
900 mm
1100 mm
1100 mm
900 mm
Max. Turning Length
850 mm
1000 mm
1000 mm
850 mm
Rotary Tool r/min
3000 r/min
3000 r/min
N/A
N/A

Puma VT900M

Single Turret Vertical Turret Lathe

Doosan Puma VT900M Single Turret Vertical Turret Lathe
  • 24” chuck
  • 45kW/1800rpm spindle
  • 900 mm max turning diameter
View machine

Puma VT1100M

Single Turret Vertical Turret Lathe

Doosan Puma VT1100M Single Turret Vertical Turret Lathe
  • 32” chuck
  • 60kW/850rpm spindle
  • 1100 mm max turning diameter
View machine

Puma VT1100

Single Turret Vertical Turret Lathe

Doosan Puma VT900 Single Turret Vertical Turret Lathe
  • 32” chuck
  • 60kW/850rpm spindle
  • 1100 mm max turning diameter
View machine

Puma VT900

Single Turret Vertical Turret Lathe

Doosan Puma VT900 Single Turret Vertical Turret Lathe
  • 24” chuck
  • 45kW/1800rpm spindle
  • 900 mm max turning diameter
View machine

Compatible Control Systems

The Puma VT900M is compatible with Fanuc and Siemens.
