Doosan DNM Series

The Doosan DNM series is one of the most popular and versatile range of vertical machining centers.

  • X-Axis Travel - 520 - 2,160mm
  • Spindle taper - 40, 50
  • Spindle RPM - 8,000 - 15,000
Share this series

or copy link

DOOSAN's Best seller of VMC, DNM series
DOOSAN's Best seller of VMC, DNM series

So long as you don’t have heavy duty requirements, the DNM vertical machining center series is almost certain to have the right machine for your needs. These versatile machines include roller guideways on a newly-designed machine base, and with 40 and 50 taper spindle options, the DNM series has an option for almost every requirement.

Technical Specification

X Axis Travel distance 520 - 2160mm
Y Axis Travel distance 400 - 762mm
Z Axis Travel distance 480 - 650mm
X Axis Rapid Traverse 24 - 48m/min
Y Axis Rapid Traverse 24 - 48m/min
Z Axis Rapid Traverse 24 - 48m/min
Max. Spindle Speed 12000 - 15000r/min
Max. Spindle Power 18 - 22kW
Max. Spindle Torque 117 - 353N·m
Tool Taper
Table Length 650 - 12000mm
Table Width 400 - 760mm
Max. Table Weight 400 - 1800kg
No. of tool station 20 - 60

Series Dimensions

Length 2158 - 3480mm
Width 1650 - 4900mm
Height 2753 - 3385mm
Weight 3300 - 15300kg

Image representative of Series and may not be the exact model

The Doosan DNM Series is compatible with Fanuc, Siemens and Heidenhain.

The Mills CNC Projects' Team, incorporating experienced engineers, will undertake a site survey and create a tailored machine delivery and installation plan that is pre-agreed with customers.

The project team will then manage the whole process and act as a seamless interface between the customer, Mills CNC and any required 3rd party specialist service providers through delivery, installation and commissioning of the machine

Talk to Mills about this series

Whether you’re ready to order or want some more details about this product, fill out our enquiry form and we’ll get right back to you.

"*" indicates required fields

Related Case Studies

DNM 750 II with doors closed at Wordsley Engineering

Great machines. Great service. Great decision.

DNM 750 II Vertical Machining Centre

Wordsley General Engineering’s decision to invest in a DNM 750 II vertical machining centre and Puma 4100LB horizontal lathe from Mills CNC is paying dividends resulting in the company having a full order book.

Operator standing by the doors of a DN Solutions DNM 5700 machining centre

A choice made pure and simple

Doosan DNM 5700 Vertical Machining Centre

Mills CNC supplied Pure Innovate Manufacturing, a leading project management and engineering solutions provider, with a new, high-performance DN Solutions’ DNM 5700 machining centre at the company’s brand new, modern and spacious Innovation facility in Wallingford, Oxfordshire.

Lynx 2100 lathe from Mills CNC, installed at MJ Engineering

Expanding capacity with CNC investment

DNM 6700 Vertical Machining Centre

Market Harborough based MJ Engineering Ltd, operating in the motorsport, oil & gas and aerospace sectors, significantly increased its machining capacity with three new CNC machine tools equipped with the latest Fanuc controls from Mills CNC.

Related Series from Vertical Machining Centres

  • Rapid rates: 42m/min
  • Spindle: Built-in 37kW/15,000rpm (214N-m)
  • Thermal compensation systems
View Series
  • Box guide-way, heavy-duty design and build
  • BT 40 or BT 50 spindle/tooling configuration
  • Gear-box driven & built-in spindle options
  • Fanuc or Siemens control
View Series
  • X-Axis Travel - 770mm
  • Spindle Taper - 40
  • Spindle RPM - 12,000
View Series
